The Goods: The New Market-Leading, AS5216:2021 Compliant, Concrete Screwbolt - ICCONS Thunderbolt Pro
02 September 2021
On this page
ICCONS Thunderbolt ® Pro is the latest high tensile screw-in,
self-tapping concrete and masonry anchor for use in a wide range of base materials such as solid and hollow brickwork, block, un-cracked and cracked concrete. The Thunderbolt ® Pro is the most complete concrete screw bolt range on the market, suitable for projects in the DIY, residential, commercial, and even major infrastructure spaces. The entire range is equipped with ETA assessments for cracked concrete, fire performance and seismic ratings (please see technical data for specification requirements). Ranging from 5mm to 18mm in various lengths, ICCONS new and improved Thunderbolt Pro is your concrete fixing for all applications such as simple fixtures, pallet racking and shelving to demanding structural steel applications.
ICCONS Thunderbolt ® Pro's aggressive thread design achieves the highest loads while generating low expansion forces which can make it a great alternative to expansion anchors such as Dynabolts or Sleeve Anchors. Tired of removing dynabolts? Look no further!
Further, the entire Thunderbolt ® Pro range has been subject to extensive testing protocols and comes fully equipped with redundant non-structural systems assessment for 5mm, seismic C1 assessment for 6mm and seismic C1 and C2 assessment for the remaining range.
Features and Benefits:
- Compliant to the requirements of AS5216:2021 (Australian Standard for Post Installed and Cast In Anchors in Concrete)
- ETA assessed for cracked concrete and fire performance
- Flanged hex head design with “lightning bolt” locking serrations for secure fixture and minimising over torque
- Available in countersunk head for flush, aesthetic finish
- Available in internal thread head designs for threaded rod applications
- Stamped head marking for easy identification and traceability
- Zinc and corrosion resistant Nautilus ® C coating options
- Fast installation at reduced torque
- No expansion, ideal for close to edge applications
- Suitable for installation with impact drivers (see technical specification for installation torque)
- Fully removable
- Available on ICCONS DesignFix software
Should you require anymore information - please don't hesitate to get in touch with our technical experts via [email protected] or alternatively call us on 03 9706 4344.
As always, follow us on Instagram, Facebook and LinkedIn to stay in touch with other relevant updates!
